Application
Fixed box-type ring network switchgear for 12kV class distribution systems. It is used in 12kV ring network distribution, compact substations and cable distribution projects. The final configuration is developed from the submitted SLD, BOQ and technical specification.
Configurable scope
- Electrical scheme and feeder arrangement based on approved drawings
- Cabinet structure, enclosure dimensions and cable entry direction
- Protection, metering, control and indication components
- Factory routine inspection, packing and export delivery coordination
- Load switch, fuse combination, RMU functions and cable branch arrangement
- Compact layout, cable entry direction and enclosure requirement
Typical RFQ information
- Rated voltage, current and short-circuit requirement
- Single-line diagram and functional units
- Installation environment and enclosure requirement
- Preferred protection, metering and switching components
- Destination country and project schedule
Common applications
- Industrial power distribution and production workshops
- Commercial building electrical rooms and utility rooms
- Infrastructure, outdoor distribution and project package supply
- Drawing-led EPC procurement where final scope is confirmed by technical documents
Standards and documentation
HXGN15-12 Box-type fixed metal closed ring network switchgear can be configured for project requirements and applicable IEC or GB standards. Final compliance, test documents and drawings should be confirmed against the approved technical specification.
FAQ
Is HXGN15-12 used for ring network applications?
Yes. HXGN15-12 is commonly configured for ring network switching, cable distribution and compact medium-voltage distribution rooms.
Can Zejiefu quote from incomplete information?
Yes. You can send available drawings and requirements first. Missing ratings, enclosure details and component choices can be clarified during engineering review.
Is online pricing available?
No fixed online price is shown because each cabinet or box is configured according to project drawings, quantities and destination requirements.
Configuration inputs
Provide the single-line diagram, required standard, system ratings, installation conditions and preferred component make. Our technical response will identify the proposed scope and any deviations.
Available options
Electrical scheme, enclosure structure, feeder arrangement, protection and metering components, cable entry, IP rating, packing and documentation.
Frequently asked questions
Can this equipment be manufactured to our SLD?
Yes. The final configuration is developed from approved drawings, ratings and component schedules.
Which documents are needed for a quotation?
Send the SLD, BOQ or specification, quantity, destination country and requested delivery schedule.
Are tests and reports available?
Available routine tests and documents depend on product scope. Only confirmed reports will be included in the proposal.
